Description
Optical System
• Microscope Type: Galilean optical system with revolving drum magnification changer
• Eyepiece: 12.5X
• Total Magnifications: 6.3X, 10X, 16X, 25X, 40X
• Pupillary Range: 52mm – 85mm
• Diopter Adjustment: ±7D
Slit Illumination
• Slit Width: 0 – 14mm continuously adjustable
• Slit Length: 1mm – 14mm continuously adjustable
• Slit Angle: 0° – 180° continuously adjustable
• Slit Aperture Sizes: 0.2, 1, 3, 5, 10, 14mm
• Tilting Illumination: 5°, 10°, 15°, 20°
• Filters: Heat Absorption, Grey, Red-free (Green), Cobalt Blue
Light Source
• Warm LED illumination (energy efficient with excellent color rendering)
Additional Features
• Haag-Streit type
• Multiple aperture and slit settings for full diagnostic flexibility
• High-contrast optics with excellent depth of field
